SS304 or SS316 Flat Foil Reinforced Graphite Gaskets

The SS304 or SS316 Flat Foil Reinforced Graphite Gasket dimension can be 15001500mm, 12001200mm, 10001000mm, 10002000mm

Content

SS304 or SS316 Flat Foil Reinforced Graphite Gaskets - T310

SS304 or SS316 flat foil reinforced graphite gaskets is cutted from plain SS304 or SS316 sheet sandwich between two layers of flexible pure graphite sheet. And this kind of reinforced graphite gaskets are suitable for metallic, glass, enamel flanges and are designed for trouble free change over which ultimately reduces maintenance cost. They are dimensionally stable under extreme pressure surge. These are also suitable for cryogenic services.

Advantages:

The reinforcement of SS304 or SS316 flat foil reinforced graphite gaskets increases mechanical strength of the gasket, it had good chemical properties of flexible pure graphite remain intact, it can be resistant to almost all non-chemicals and has good compressibility and recovery, hence seals perfectly, does not age or creep under hot or cold working conditions

Typical Applications:

SS304 or SS316 flat foil reinforced graphite gasket can be used for any type of Pipe flanges, Valve bonnets and Heat exchangers.

Service Media:

It can be used for super heated and saturated steam, All non-oxidising liquids and gases, Hydrocarbon, Oxygen services, Cryogenic services, Dyes and chemicals, Fuel and lube oil etc.

Data Sheet

data sheet of SS304 or SS316 Flat Foil Reinforced Graphite Gasket
